Chatillon - DFS II Series Digital Force Gauges
Model:
DFS2-200
Capacity:
200lb
Readability:
0.04lb
Features
- - Bluetooth, USB, RS-232, and analog communication
- - Normal and Peak operating modes
- - Integral load Cell
Description
The DFS II Series offers the best price performance of any digital force gauge available. The gauge is the first of its type to offer wireless data transfer and communication.
This compact force gauge is designed for basic and advanced applications. ideal for hand-held, field or test stand application, and can be equipped with integral load cells of external self-recognizing load and torque cells,
A large, high resolution, full color LCD display supports a variety of standard gauge functions including normal and peak readings, high/low limits, set points, pass/fail results, and load averaging. Loads are displayed in ozf, gf, lbf, kgf, and N units
Accessories
| Part Number | Description |
|---|---|
| SPK-FMG-008A | Chisel Point, 100lbf (#10-32) |
| SPK-FMG-008B | Chisel Point, 500lbf (5/16-18) |
| SPK-FMG-009A | Point, 100lbf (#10-32) |
| SPK-FMG-009B | Point, 500lbf (5/16-18) |
| SPK-FMG-010A | Notch, 100lbf (#10-32) |
| SPK-FMG-10B | Notch, 500lbf (5/16-18) |
| SPK-FMG-011A | Flat, 100lbf (#10-32) |
| SPK-FMG-011B | Flat, 500lbf, (5/16-18) |
| SPK-FMG-012A | Hook, Stationary, 50lbf (#10-32) |
| SPK-FMG-012B | Hook, Stationary, 100lbf, (#10-32) |
| SPK-FMG-012C | Hook, Stationary, 500lbf (5/16-18) |
| SPK-FMG-013A | Extension Rod, Low Capacity (#10-32) |
| SPK-FMG-013B | Extension Road, High Capacity (5/16-18) |
| SPK-DF2-UNIV | Battery Charger |
